LeeBoy 6150 - Page 211

Item
No
Part Number Qty Description Remarks
1 1016026 2 Roller Chain, 80H x 48 Pitches
2 1007048SRV 2 Conveyor Drive Sprocket Assembly
3 1014857 2 Conveyor Drive Bearing
4 100-10-11-24-5F 2 CSHH, 5/8-11 x 1.50, GR5, FT
5 302-10 A/R Washer, Lock, 5/8
6 308-10-36 2 Washer, Flat, Fender, 5/8 x 2.25
7 100-4-20-16-5 2 CSHH, 1/4-20 x 1.00, GR5
8 302-4 2 Washer, Lock, 1/4
9 308-4-16 2 Washer, Flat, Fender, 1/4 x 1.00
10 851120 2 Conveyor Drive Motor Sprocket
11 1016028 2 Conveyor Motor Mount
12 105-8-13-32-F 8 CSFHS, 1/2-13 x 2.00, FT
13 204-8-13-5 A/R Nut, Lock, Stover, 1/2-13, GR5
14 260130 2 Hydraulic Motor, 22.0 CIR
15 6400-8-10-O 2 Straight Adapter, -8 JIC / -10 O-Ring
16 6801-8-10 NWO 2 Elbow Adapter, 90°, -8 JIC / -10 O-Ring
17 1016488 1 Paddle Weldment - Left
18 1016489 1 Paddle Weldment - Right
19 100-8-13-48-5 2 CSHH, 1/2-13 x 3.00, GR5 Included with Items 17 & 18
20 202-8-13-5 2 Nut, Hex, Jam, 1/2-13, GR5 Included with Items 17 & 18
21 900050SRV 2 Conveyors Automatic Micro Switch
22 900060 2 Conveyor Switch Arm
23 1009714 2 Paddle Linkage Rod
24 13A-0212ZI 4 Cotter Pin, 1/16 x 3/4 Plated Not Shown
25 122-#10-32-32F 4 PHMS, Cross, #10-32 x 2.00, FT
26 205-#10-32-5 4 Nut, Lock, Nylon, #10-32, GR5
27 1009452 4 Conveyor Paddle Pin
28 100-7-14-20-5 4 CSHH, 7/16-14 x 1.25, GR5
29 302-7 4 Washer, Lock, 7/16
30 300-7 4 Washer, Flat, SAE, 7/16
Conveyor Assembly (3 of 3)
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-17
