Item
No
Part Number Qty Description Remarks
1 1016084 1 Front Conveyor Chain Cover
2 1016085 1 Center Flashing
3 1016086 1 Center Flashing Mounting Bar
4 301-8 A/R Washer, Flat, USS, 1/2
5 204-8-13-5 A/R Nut, Lock, Stover, 1/2-13, GR5
6 1017390 2 Long Guide Bar
7 100-6-16-16-5F A/R CSHH, 3/8-16 x 1.00, GR5, FT
8 300-6 A/R Washer, Flat, SAE, 3/8
9 204-6-16-5 6 Nut, Lock, Stover, 3/8-16, GR5
10 920061-1 2 Chain, 1/4 x 12 Link
11 920070 2 Thumb Screw, 3/8-16 x 1.00
12 1017616 1 Hopper Cylinder Assembly - Left Includes Items 12-15
REF 1017617 1 Hopper Cylinder Assembly - Right Includes Items 12-15
REF 20924387 2 Hopper Lift Cylinder, 2B x 1.062R x 13S
13 20925244 4 Clevis Pin Included With Item 12
14 15491939 4 Cotter Pin Included With Item 12
15 2501-6-6 X 078 4 Elbow Adapter, 90°, -6 JIC / -6 NPTF, .078 Included With Item 12
16 1015988 1 Hopper Weldment - Left
17 1015987 1 Hopper Weldment - Right
18 1007396 2 Hopper Hinge Pin
19 400-4-20 2 Roll Pin, 1/4 x 1.25
20 1016520 2 Hopper Scraper Plate
21 302-6 10 Washer, Lock, 3/8
22 1011900 2 Hopper Wing Flashing, Thick
23 1007104 2 Sidewing Rubber Shield Plate
24 100-8-13-40-5 A/R CSHH, 1/2-13 x 2.50, GR5
25 1000806SRV 1 Hopper Wing Guide Assembly - Left Includes Items 25,26
REF 1000801SRV 1 Hopper Wing Guide Assembly - Right Includes Items 26,27
REF 1000805 1 Guide Bracket - Left
26 1000803 2 Guide Bar
27
1000804 1 Guide Bracket - Right
28 100-6-16-20-5 4 CSHH, 3/8-16 x 1.25, GR5
Hopper Wings
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-19
