LeeBoy 6150 - Page 223

Engine Assembly - Radiator
Item
No
Part Number Qty Description Remarks
GRP 1017239 Group - Engine, 150D
1 988673-13 1 Radiator/Cooler Assembly
2 1002184-04 1 Radiator Cap
3 6400-12-12-O 2 Straight Adapter, -12 JIC, -12 O-Ring
4 1016478-01 1 Radiator Fan
5 1002006-54 1 Fan Guard
6 1006963-15 1 Upper Radiator Hose
7 1001166-57 5 Isolator
8 986537-46 1 Coolant Recovery Tank
9 1006963-16 1 Lower Radiator Hose
10 1009384-12 1 Lower Radiator Mount
11 1009384-18 1 Radiator Support Bracket
12 1009384-13 1 Stabilizer Brace
13 100-6-16-36-5 1 CSHH, 3/8-16 x 2.25, GR5
14 301-6 1 Washer, Flat, USS, 3/8
15 308-6-24 1 Washer, Flat, Fender, 3/8 x 1.50
16 1009384-17 1 Radiator Brace
17 986537-17 1 Front Motor Mount - Right
18 986537-16 1 Front Motor Mount - Left
19 988673-14 2 Rear Motor Mount
20 986537-14 4 Isolator
21 100-8-13-24-8 8 CSHH, 1/2-13 x 1.50, GR8
22 986810 8 Washer, Lock, 1/2, Nord Wedge
23 1017061 8 Washer, Triangle Engine Mount
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-29
