Engine Assembly - Components (1 of 2)
Item
No
Part Number Qty Description Remarks
GRP 1017239 Group - Engine, 150D
1 1009253-18 1 Fuel Filter
2 1009253-19 1 Fuel/Water Separator Filter
3 1010471 1 Fuel Pump w/Filter
4 1016249-08 1 Fuel Filter Mount
5 1016249-07 1 Fuel Pump/Filters Mount
6 1009253-24 1 ECU
7 1009253-01 1 ECU Mounting Bracket
8 986537-03 1 Oil Filter
9 1011799-67 1 Engine Fuse/Relay Box See Figure 7-14
10 1015908-07 1 Fuse Box Mounting Bracket
11 Purchase Locally 1 12V Battery, Group 31, 925 CCA @ 0°F, AGM-200
12 1013944 1 Battery Hold Down Plate
13 100-6-16-128-5 2 CSHH, 3/8-16 x 8.00, GR5
14 300-6 2 Washer, Flat, SAE, 3/8
15 720130 1 Battery Tray Pad
16 SW29 1 Battery Disconnect Switch
17 1015908-04 2 Battery Cable, Eye/Eye
18 1015908-06 1 Battery Cable, Eye/Eye-Battery Negative to Starter
19 1015908-05 1 Battery Cable, Eye/Eye-Battery Negative to Ground
20 1009253-27 1 Main Fuse Assembly
21 1005908-08 1 Grid Heater Relay
7
