LeeBoy 6150 - Page 235

Item
No
Part Number Qty Description Remarks
1 1015114 1 Deck Cover - Right
2 1016699 1 Fender Cover Panel - Right
3 1016060 1 Splash Guard
4 1016064 1 Side Cover - Right
5 720100 A/R Edge Trim
6 1016068 1 Door - Right
7 980460 3 Lever Latch
REF 35560 A/R Replacement Key Included With Item 7
8 1016683 1 Screed Arm Rub Block
9 1016491 1 Toe Cover - Right
10 1008961 1 Floor Board Grating - Right
11 1016051 1 Center Cover Panel
12 1016056 1 Hood Mount
13 1016069 1 Air Filter Mounting Bracket
14 1015047 1 Intake Access Plate - Right
15 1016054 1 Exhaust Cover
16 1015116 1 Hydraulic Pump Vent - Right
17 1016058 1 Access Door
18 100-5-18-16-5F A/R CSHH, 5/16-18 x 1.00, GR5, FT
19 302-5 A/R Washer, Lock, 5/16
20 300-5 A/R Washer, Flat, USS, 5/16
21 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
22 302-6 5 Washer, Lock, 3/8
23 300-6 5 Washer, Flat, SAE, 3/8
24 200-5-18-5 3 Nut, Hex, 5/16-18, GR5
25 105-5-18-20-F 3 CSFHS, 5/16-18 x 1.25, FT
26 100-6-16-32-5 3 CSHH, 3/8-16 x 2.00, GR5
27 987021 3 Mounting Tab
28 100-5-18-12-5F 4 CSHH, 5/16-18 x .75, GR5, FT
29 120-6-16 2 Wing Screw, Type C, 3/8-16 x 1.00, Cup
30 100-6-24-16-5F 4 CSHH, 3/8-24 x 1.00, GR5, FT
Hoods and Covers - Right
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-41
