LeeBoy 6150 - Page 237

Item
No
Part Number Qty Description Remarks
REF 1015438 1 Spraydown Pump w/Pressure Switch Includes Items 1-4
1 1015438-01 1 Spraydown Pump Body
2 1015438-02 1 Pressure Switch
3 1015089-04 2 Straight Adapter, -6 BSPP / -6 NPT
4 1015089-05 4 Isolator
5 122-#10-24-20F 4 PHMS, Cross, #10-24 x 1.25, FT
6 300-#10 8 Washer, Flat, SAE, #10
7 205-#10-24-5 4 Nut. Lock, Nylon, #10-24
8 2502-6-6 2 Elbow Adapter, 90°, -6 JIC / -6 NPTF
9 5LOC-6RFJX 7 Push Lok Fitting, -5 LOC / -6 RFJX
10 33277 2 Hose Clamp, #04 (.22 - .62)
11 71812 A/R Push-On Hose, 05 (.3125)
12 986537-31 1 Fuel Filter, Inline
13 920200 2 Spraydown Reel w/Hose
14 920220 2 Washdown Handle & Nozzle
REF 901210A A/R Washdown Nozzle Included With Item 14
15 100-5-18-40-5 8 CSHH, 5/16-18 x 2.50, GR5
16 300-5 16 Washer, Flat, SAE, 5/16
17 302-5 12 Washer, Lock, 5/16
18 200-5-18-5 8 Nut, Hex, 5/16-18, GR5
19 2501-6-6 2 Elbow Adapter, 90°, -6 JIC / -6 NPTF
20 2603-6-6-6 1 Union Tee Adapter, -6 JIC / -6 JIC / -6 JIC
21 1016704 1 Spraydown Pump Cover
22 1016094 1 Decal - Instructional, Spray Down Pump
23 100-5-18-16-5F 4 CSHH, 5/16-18 x 1.00, GR5, FT
24 301-5 4 Washer, Flat, USS, 5/16
25 2404-6-6 1 Connector Adapter, -6 JIC / -6 NPTF
26 480160 1 Ball Valve, 3/8
27 1404-6-6 1 Union to Male Pipe Adapter, -6 NPTF
28 5500-6-6 1 Elbow Adapter, 90°, -6 NPTF / -6 NPTF
Spray Down
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-43
