Item
No
Part Number Qty Description Remarks
1a 1016116 1 Screed Arm - Left (1) Left, (1) Right
1b 1016117 1 Screed Arm - Right (1) Left, (1) Right
2 100-8-13-28-5 8 CSHH, 1/2-13 x 1.75, GR5 (3) Left, (3) Right
3 300-8 A/R Washer, Flat, SAE, 1/2 (1) Left, (1) Right
4 204-8-13-5 A/R Nut, Lock, Stover, 1/2-13, GR5 (1) Left, (1) Right
5 1016106 2 Screed Arm Outer Bar (2) Left, (2) Right
6 100-12-10-48-5 4 CSHH, 3/4-10 x 3.00, GR5 (2) Left, (2) Right
7 300-12 8 Washer, Flat, SAE, 3/4 (2) Left, (2) Right
8 100-8-13-44-5 6 CSHH, 1/2-13 x 2.75, GR5 (1) Left, (1) Right
9 100-9-12-40-5 4 CSHH, 9/16-12 x 2.50, GR5 (1) Left, (1) Right
10 300-9 8 Washer, Flat, SAE, 9/16 (1) Left, (1) Right
11 204-9-12-5 4 Nut, Lock, Stover, 9/16-12, GR5 (1) Left, (1) Right
12 1010996 4 Round Bar Spacer (1) Left, (1) Right
13 1016799 2 Tow Indicator (2) Left, (2) Right
14 1016113 2 Screed Arm Actuator Mount (2) Left, (2) Right
15 851518 2 Linear Actuator, 12V, 6.00" (2) Left, (2) Right
16 1016796 2 Decal - Tow Point Thickness Indicator (1) Left, (1) Right
17 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT (1) Left, (1) Right
18 302-6 2 Washer, Lock, 3/8 Includes Items 20 - 24
19 308-6-24 2 Washer, Flat, Fender, 3/8 x 1.50 Not Shown, Includes Items 20 - 24
20 300-6 2 Washer, Flat, SAE,3/8 (1) Per Assembly
21 851212 2 Linear Actuator Rod End (1) Per Assembly
22 140620 2 Lube Fitting, 90°, 1/4-28 (1) Per Assembly
23a 1016118 1 Screed Arm Actuator Mount - Left (2) Left, (2) Right
23b 1016119 1 Screed Arm Actuator Mount - Right (2) Left, (2) Right
24 20961769 8
Spacer (1) Left, (1) Right
25 20961736 4 Bar
26 100-12-10-36-5 4 CSHH, 3/4-10 x 2.25, GR5
27 302-12 4 Washer, Lock, 3/4
Tow Point Assembly
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-45
