LeeBoy 6150 - Page 241

Hydraulic Manifold - Upper
Item
No
Part Number Qty Description Remarks
REF 1017482 1 Upper Manifold Assembly Includes Items 1-14
1 1011728 1 Hydraulic Manifold, 9-Station, 7 Valve Includes Items 2-9
2 983643-05 A/R Dual Pilot Operated Check Valve
3 983643-09 A/R CV08 Check Valve
4 1011728-01 A/R Direction Solenoid Valve Includes Item 5
5 1011728-02 A/R 12VDC Coil w/Deutsch Connector
6 983643-08 A/R CV04 Check Valve
7 983643-10 A/R FD10 Flow Divider
8 983643-07 A/R RV08 Relief Valve
9 983643-06 A/R Piloted Logic Element Valve
10 6801-10-10 NWO 1 Elbow Adapter, 90°, -10 JIC / -10 O-Ring
11 6400-10-10-O 1 Straight Adapter, -10 JIC / -10 O-Ring
12 6400-4-6-O 4 Straight Adapter, -4 JIC / -6 O-Ring
13 6400-6-6-O 8 Straight Adapter, -6 JIC / -6 O-Ring
14 6408-6-O 7 Plug Adapter, -6 O-Ring
REF 1017607 1 High Pressure Filter Assembly Includes Items 15-17
15 984594 1 Hydraulic Filter Assembly, 3000 PSI, 25 GPM
16 6400-10-12-O 1 Straight Adapter, -10 JIC / -12 O-Ring
17 6801-10-12 NWO 1 Elbow Adapter, 90°, -10 JIC / -12 O-Ring
18 1016212 1 Filter Mounting Bracket
19 1016091 1 Upper Manifold Mounting Bracket
20 100-4-20-16-5F 2 CSHH, 1/4-20 x 1.00, GR5, FT
21 302-4 2 Washer, Lock, 1/4
22 300-4 2 Washer, Flat, SAE, 1/4
23 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
24 302-6 2 Washer, Lock, 3/8
25 300-6 2 Washer, Flat, SAE, 3/8
26 100-5-18-16-5F 6 CSHH, 5/16-18 x 1.00, GR5, FT
27 300-5 6 Washer, Flat, SAE, 5/16
28 302-5 4 Washer, Lock, 5/16
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-47
