LeeBoy 6150 - Page 249

Item
No
Part Number Qty Description Remarks
1 1016034 1 Control Box Assembly See Figure 7-26
2 1007337 1 Vandalism Latch Bar
3 1007339 1 Vandalism Cover Assembly
4 1015406 2 Steering Wheel Box (For Plus 1)
5 1000708-02 2 Decal - Operation, Steering Wheel Box
6 1005474 2 Decal - Safety, No Unattended
7 1012360 2 Joystick Box Mount
8 120-6-16 4 Wing Screw, Type C, 3/8-16 x 1.00, Cup Included with Item 8
9 1002546SRV 1 Cup Holder - Left
10 1002547SRV 1 Cup Holder - Right
11 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
12 300-6 8 Washer, Flat, SAE, 3/8
13 204-6-16-5 4 Nut, Lock, Stover, 3/8-16, GR5
14 100-4-20-16-5F 4 CSHH, 1/4-20 x 1.00, GR5, FT
15 300-4 8 Washer, Flat, SAE, 1/4
16 200-4-20-5 4 Nut, Hex, 1/4-20, GR5
17 204-4-20-5 4 Nut, Lock, Stover, 1/4-20, GR5
18 100-5-18-16-5F 2 CSHH, 5/16-18 x 1.00, GR5, FT
19 300-5 12 Washer, Flat, SAE, 5/16
20 100-6-16-26-5 2 CSHH, 3/8-16 x 1.625, GR5
21 1007338 2 Vandalism Cover Spacer
22 100-5-18-12-5F 8 CSHH, 5/16-18 x .75, GR5, FT
23 302-5 8 Washer, Lock, 5/16
Dash Assembly - Controls
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-55
