Option - Electric Screed Control Assembly
Item
No
Part Number Qty Description Remarks
REF 1016891 1 Control Box Assembly, 10kW
1 100804 1 Enclosure, 10 x 8 x 4
2 851393 3 Toggle Switch
3 982249 1 Push Button Switch
4 1011180 1 Decal - Electric Heat
5 1017228 2 Water Tight Conduit Connector
6 985140 5 Circuit Breaker, 15A, Pan Mount
7 1009228 8 Circuit Breaker, 10A
8 35136-7 2 Plastic Hole Plug, .875, Flush Mount
9 1016892 1 Circuit Breaker Boot
10 31983 1 Red Light
11 985687 1 Amphenol Connector, 06-Pin Male
12 988230 1 Time Delay Relay, ON, 10A
13 985142 1 Electric Timer, 06 - 60 MIN
14 988231 1 Off Delay Timer, 5 Seconds
15 1017190 1 AC Detector, Generator Control
16 1016901 1 Circuit Breaker, 40A, Generator Protection
17 985138-04 1 Terminal Block w/Cover
18 985141 4 Relay, 12VDC, DSPT, 25A, N/O
19 100-4-20-12-5F 4 CSHH, 1/4-20 x .75, GR5, FT
20 302-4 4 Washer, Lock, 1/4
21 200-4-20-5 4 Nut, Hex, 1/4-20, GR5
REF 1016723 1 Load Control Box to Bulkhead Harness Not Shown
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-101
