LeeBoy 6150 - Page 299

Option - Generator
Item
No
Part Number Qty Description Remarks
1 1017009 1 Generator Assembly, 10kW Includes Item 2-4
2 1014873-02 1 Bent Axis Piston Motor, 10 CC
3 1016815 1 Decal - Circuit Breaker
4 1017057 1 Circuit Breaker, 50A
5 6400-6-6-O 1 Straight Adapter, -6 JIC / -6 O-Ring
6 6801-10-12 NWO 1 Elbow Adapter, 90°, -10 JIC / -12 O-Ring
7 6802-12-12 NWO 1 Elbow Adapter, 45°, -12 JIC / -12 O-Ring
8 6602-12-12-12 1 Swivel Run Tee Adapter, -12 JIC / -12 JIC / -12 JIC
9 2406-12-6 1 Reducer Adapter, -12 JIC / -6 JIC
10 1016859 1 Generator Mounting Plate - Rear
11 1005555 1 Spacer
12 100-6-16-24-5 2 CSHH, 3/8-16 x 1.50, GR5
13 300-6 4 Washer, Flat, SAE, 3/8
14 204-6-16-5 2 Nut, Lock, Stover, 3/8-16, GR5
15 100-5-18-16-5F 2 CSHH, 5/16-18 x 1.00, GR5, FT
16 302-5 2 Washer, Lock, 5/16
17 300-5 3 Washer, Flat, SAE, 5/16
18 100-5-18-24-5 1 CSHH, 5/16-18 x 1.50, GR5
19 204-5-18-5 1 Nut, Lock, Stover, 5/16-18, GR5
20 1006953-17 1 Test Port w/Cap
21 6801-10-10 NWO 3 Elbow Adapter, 90°, -10 JIC / -10 O-Ring
22 1017191 1 Valve Driver, EGDR-0101A, 10 kW
23 6801-12-12 NWO 1 Elbow Adapter, 90°, -12 JIC / -12 O-Ring
24 6400-12-12-O 2 Straight Adapter, -12 JIC / -12 O-Ring
25 1016128 1 Hydraulic Pump, 22.5 CC, 9T
26 36808 1 O-Ring, 3.237 ID x 103, SAE 152 Not Shown
27 1016968 1 Auxiliary Drive PTO, HD9
28 102-M10-1.5-30-8.8F 2 CSSH, M10x1.5 x 30, C8.8, FT
29 302-M10 2 Washer, Lock, M10
30 1016316 1 Strainer, 100 Mesh, 5 PSI Relief, 25 GPM
31 6400-12-20-O 1 Straight Adapter, -12 JIC / -20 O-Ring
32 6502-12-12
1 Elbow Adapter, 45°, -12 JIC / -12 JIC
REF 1016970 1 Electric Option Hydraulic Hose Kit Not Shown
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-105
