LeeBoy 6150 - Page 305

Item
No
Part Number Qty Description Remarks
1 1016475 1 Wear Plate w/Studs, 3/8”
2 1007001 24 Wear Plate Spacer
3 1015016SRV 2 S-Style Heating Element, 2000W/240V
4 1015018 2 HD Screed Insulation
5 1016582 6 Bar, .375 x 1.50 x 37.50
6 1016477 2 S-Style Element Cover
7 100-6-16-40-5 18 CSHH, 38-16 x 2.50, GR5
8 202-6-16-5 18 Nut, Hex, Jam, 3/8-16, GR5
9 1016480 6 S-Style Element Stop Bar
10 1016476 6 S-Style Element Hold Down Bar
11 1016481 1 S-Style Element End Cover - Right
12 1016483 1 S-Style Element End Cover - Left
13 981710L 1 Hydraulic Cylinder, 2.00 x 2.00 x 42.00 x 1.25 Rod
14 981710R 1 Hydraulic Cylinder, 2.00 x 2.00 x 42.00 x 1.25 Rod
15a 1016151SRV 2 Manual Turnbuckle Assembly Standard
15b 983421 2 Hydraulic Cylinder, 2.75 x 2.00 x 1.125 Rod Option - Hydraulic Slope
GRP 1007212 Group - Mechanical Crown
16 1009439 1 Crown & Valley Assembly
17 1009440 1 Crown & Valley Turnbuckle Assembly
18 1006419 2 Crown Mounting Spacer
19 1008047 1 Roller Chain, 60H x 39P w/Half-Link & Masterlink
Option - HD Screed Frame Assembly (2 of 2)
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-111
