LeeBoy 6150 - Page 32

Table 2-8. Generator Specications
ITEM SPECIFICATION
Power 10 kW
Voltage 120/240 Volts
Frequency 60 Hz
Table 2-10. Hydraulic Pressures Specications
ITEM SPECIFICATION
Drive Pump 3625 psi (249.9 Bar)
Conveyor Pump 2900 psi (179 Bar)
Auger Pump 2900 psi (179 Bar)
General Purpose Pump (Cylinders) 2900 psi (179 Bar)
Generator Pump 2900 psi (179 Bar)
Table 2-11. Hopper Specications
ITEM SPECIFICATION
Material Capacity 7 Tons (6.4 Tonnes)
Height 23 in (584 mm)
Wings 3/8 in (10 mm)
Table 2-12. Auger and Conveyor Specications
ITEM SPECIFICATION
Maximum Auger Speed 145 RPMs
Maximum Conveyor Speed 74 FPMs (22.5 MPMs)
Table 2-14. Screed Specications
ITEM
SPECIFICATION
Legend Screed 815HD (Option)
Screed Weight 2900 lbs (1315 kg) 3300 lbs (1678 kg)
Screed Heat
Propane (Standard) Electric (Option) Electric
Two (2) LP burners on main
screed and one (1) LP burner
on each screed extension.
54,000 BTUs
Two (2) 1750-watt electric
heat elements on main
screed.
One (1) 1000-watt electric
heat element on each
screed extension.
Two (2) 2000-watt S-Curve
electric heat elements on main
screed.
One (1) 1000-watt electric
heat element on each screed
extension.
Screed Width MAIN: 8 ft (2.6 m) EXTENSIONS: 3 ft 6 in (30 cm) each
Wear Plate Depth
and Thickness
MAIN SCREED: DEPTH: 15.4 in (391 mm) THICKNESS: .375 in (9.5 mm)
EXTENSION: DEPTH: 6.75 in (171 mm) THICKNESS: .25 in (6.35 mm)
Bullnose Radius MAIN: 1.375 in (35 mm) 1 in (25.4 mm)
Vibration Two (2) hydraulic vibrators producing 2400 vpm.
Positive/Negative
Crown
POSITIVE: 2 in @ 10 ft (50.8 mm @ 3 m)
NEGATIVE: 1.50 in @ 10 ft (38.1 mm @ 3 m)
LeeBoy 6150 Conveyor Paver
2-6
Information and Specications
