LeeBoy 6150 - Page 339

Item
No
Part Number Qty Description Remarks
OPT 985797SRV Option - 12” Auger Extension
REF 985795 1 12” Auger Extension Assembly - Left Includes Items 1, 3 - 6
REF 985796 1 12” Auger Extension Assembly - Right Includes Items 2 - 6
1 981700L 1 12” Auger Flight - Left
2 981700R 1 12” Auger Flight - Right
3 985794 2 Auger Extension Shaft Weldment (1) Per Assembly
4 100-10-11-44-5 2 CSHH, 5/8-11 x 2.75, GR5 (1) Per Assembly
5 302-10 2 Washer, Lock, 5/8 (1) Per Assembly
6 200-10-11-5 2 Nut, Hex, 5/8-11, GR5 (1) Per Assembly
Option - 12” Auger Extension
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-145
