LeeBoy 6150 - Page 341

Item
No
Part Number Qty Description Remarks
OPT 982521SRV 1 Option - 24" Auger Extension w/Shield
1 851228SRV 1 24" Auger Extension Shield - Left
REF 851227SRV 1 24" Auger Extension Shield - Right Not Shown
2 851230SRV 1 24" Auger Extension - Left Includes Items 3 & 4
REF 851229SRV 1 24" Auger Extension - Right Not Shown, Includes Items 3 & 4
3 854003 2 Chain Coupling Sprocket Half w/Hole
4 900404 2 Double Row Chain Assembly, 50-2
5 851231SRV 2 Auger Extension Support
6 200-16-8-5 4 Nut, Hex, 1-8, GR5
Option - 24” Auger Extension
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-147
