LeeBoy 6150 - Page 345

Option - TopCon P-32 Control Assembly (One Side)
Item
No
Part Number Qty Description Remarks
GRP 1016470 Option - TopCon P-32, Dual Grade (One Side)
1 9090-1125SRV 1 TopCon Z-Arm Bracket
2 920070 1 Thumb Screw, 3/8-16 x 1.00 Included With Item 1
3 851575SRV 1 TopCon/Spectra Pivot Mount
4 300060 1 Handle Nut, 5/8-11
5 100-10-11-32-5F 1 CSHH, 5/8-11 x 2.00, GR5, FT
6 100-10-11-20-5F 2 CSHH, 5/8-11 x 1.25, GR5, FT
7 300-10 2 Washer, Flat, SAE, 5/8
8 1010499-02 1 TopCon Sonic Tracker Bracket w/L-Bolt
9 100-12-10-64-8 1 CSHH, 3/4-10 x 4.00, GR8
10 300-12 1 Washer, Flat, SAE, 3/4
11 985866 2 AM Module & Cable Assembly Includes Items 11, 12
12 985866-01 2 AM Module Only
13 985866-02 2 AM Module Cable Only
14 1010499-08 1 GC-35 Controller Assembly
15 1010499-06 1 Sonic Tracker II Assembly
16 1010499-07 1 Temp Bail w/Sleeves Assembly
17 1010499-04 1 GC-35/Sonic Tracker Cord Assembly (15 ft.)
18 851265 1 Carrying Case
19 1010499-01 1 GC-35 Quick Reference Guide Not Shown
20 1010499-05 2 GC-35 Paver Bracket Assembly
REF 983416-01 1 Junction Box to Control Box Cable Not Shown
REF 984596 2 Cable Remote Assembly Not Shown
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-151
