Leeboy 6150 Conveyor Paver 3-7
Component Location
ITEM
NO.
CONTROL
NAME
FUNCTION
7
PV480 Digital
Display
Displays paver setup and calibration information, engine operating information, and engine and
paver system fault information.
8 Wait to Start Light Illuminates for a few seconds during start-up. Starter will not engage until this light turns off.
9 2-Speed Light Illuminates when paver is in high gear.
10 Plus One Light
The Plus One status light illuminates and blinks to alert the operator of a fault in the Plus One
controller that monitors paver control systems. (Page 5-?)
11 Posi-Trac
Activating the Posi-Trac system allows both wheels to have independent power of each other for
better traction and increased turning radius when experiencing slipping (i.e., on gravel, sand, dirt
surfaces, etc.).
12 Pivot Steer Activating the pivot steer decreases the turning radius, allowing sharper turns when needed.
13
Beacon and Work
Lights
Used to alert surrounding vehicles and pedestrians. The beacon light also comes on when the
work lights are turned on.
14 Vibrators Switch
Turns the screed vibrators on and off to help compact asphalt material while paving. Only
functions when the Run/Start switch on the steering control box is in the RUN position and the
joystick is in the FORWARD position.
15
Grade Control
Switch
When this switch is in the GRADE position, the tow point switches are enabled regardless of the
Run/Start switch position. When in the SLOPE position, the tow point switches are controlled by
the automated system when joysticks are in the FORWARD position.
16
Right Tow Thicker/
Thinner Switch
Sets the thickness of the asphalt and controls the electric ight screws. Operator can select
either THICKER or THINNER as needed. The Grade Control switch must be set to GRADE on
the control panel to turn power on for this feature.
17
High/Low 2-Speed
Gear Switch
Used to change machine speed. Place switch in HIGH position for travel (High/Low Gear light
will illuminate). Pave only in LOW speed. NEVER pave in high speed.
18 Horn Pressing this button sounds the horn.
19 E-Stop Button
Immediately stops the paver engine and all electronic functions. Turn clockwise to release
E-Stop button.
20
Left and Right
Conveyor Switches
Selects automatic or manual mode for left and right conveyors. The center position is OFF.
MANUAL position provides override. Conveyors can be operated from either side in the
MANUAL mode. For automatic operation, set switch to AUTOMATIC.
21
Screed Lift/Float
Switch
Raises or oats the screed. Flip switch to RAISE to raise the screed. Set the switch to FLOAT
to oat the screed (switch will lock in the FLOAT position). When released, switch automatically
returns to the center to hold the screed in selected position.
22
Left Extension
Switch
Extends or retracts left screed extension. Push switch IN to retract left screed extension. Push
switch to OUT to extend left screed extension. (Switch also located on the remote box on left
side of paver.)
23
Left and Right Cut-
Off Gate Switches
Opens and closes left and right Under Auger Material Cut-Offs.
24 Hopper Switch
Opens and closes hopper sidewings. Push switch to the OUT position to open hopper wings.
Push switch to the IN position to close hopper wings.
25
Right Extension
Switch
Extends or retracts right screed extension. Push switch IN to retract right screed extension.
Push switch to OUT to extend right screed extension. (Switch also located on the remote box on
right side of paver.)
