58 Legrand PDU User Guide
You can use the LCD display to view the Legrand PDU information and even switch an outlet. It consists of:
A dot-matrix LCD display
Four control buttons
Zero U models automatically adjust the orientation of the content shown on the dot-matrix LCD display after
detecting the direction in which the PDU is installed. 1U and 2U models do NOT adjust the content's
orientation.
Note: All dot-matrix LCD display diagrams illustrated in the User Guide are for Zero U models. Your
dot-matrix LCD may look slightly different if it is on a 1U/2U model.
Automatic and Manual Modes
After powering on or resetting the Legrand PDU, the front panel LCD display first shows a dark screen, then
Legrand logo and finally enters the automatic mode.
Automatic mode without alerts available:
In this mode, the LCD display cycles through the inlet information as long as there are no alerts.
If overcurrent protectors are available on your Legrand PDU, the display cycles between both the inlet and
overcurrent protector information.
Note: You can make a Legrand PDU with overcurrent protectors show the inlet information only in the
automatic mode. See Front Panel Settings (on page 224).
Manual mode:
To view more information or control outlets if your Legrand PDU is outlet-switching capable, enter the
manual mode.
Press
or to enter the manual mode, where the Main Menu is first displayed. See Main Menu (on
page 60).
To return to the automatic
mode, press
once or multiple times.
When an alert exists:
In the automatic mode, when an alert occurs, the LCD display stops cycling through the inlet information,
and warns you by showing the alerts notice in a yellow or red background. See Alerts Notice in a
Yellow or Red Screen (on page 75).
To enter the manual mode
, press
.
In the manual mode, both the top and bottom bars will turn yellow or red to indicate the presence of any
alert. See Operating the Dot-Matrix LCD Display (on page 59).
