Lenze 8200 vector series Mounting Instructions

About this documentation
Conventions used
1

104
EDK82EV903 DE/EN/FR 5.1
1 About this documentation
Validity information
These instructions are valid for
ƒ Frequency inverter E82xV153K4B
ƒ Frequency inverter E82xV223K4B
ƒ Frequency inverter E82xV303K4B
ƒ Frequency inverter E82xV453K4B
ƒ Frequency inverter E82xV553K4B
ƒ Frequency inverter E82xV753K4B
ƒ Frequency inverter E82xV903K4B
Target group
This documentation is directed at qualified skilled personnel according to IEC 60364.
Qualified skilled personnel are persons who have the required qualifications to carry out
all activities involved in installing, mounting, commissioning, and operating the product.
1.1 Conventions used
This documentation uses the following conventions to distinguish between different
types of information:
Spelling of numbers
Decimal separator
Point In general, the decimal point is used.
For instance: 1234.56
Warnings
UL warnings

Are only given in English.
UR warnings

Icons
Page reference  Reference to another page with additional
information
For instance:  16 = see page 16
Documentation reference  Reference to another documentation with
additional information
For example:  EDKxxx = see
documentation EDKxxx

Lenze 8200 vector series Specifications

General

Category	DC Drives
Overload capacity	150% for 60 seconds
Protection class	IP20
Mains voltage	380V to 480V AC
Control method	Vector control
Communication options	CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Humidity	≤ 95% relative humidity, non-condensing
Series	8200 vector
