Commissioning
Parameter setting with the XT EMZ9371BC keypad
Vector control
7
174
EDK82EV903 DE/EN/FR 5.1
7.3.2 Vector control
The following instructions apply to controllers equipped with a standard−I/O function
module and a three−phase AC motor which has been selected according to a power−based
assignment.
Switch−on sequence Comment
1. Plug in the keypad
2. Ensure that controller inhibit is active after mains connection
Terminal X3/28 = LOW
3. Switch on the mains
4. After approx. 3 s the keypad is in the operating level and displays
the output frequency (C0050) and the device utilisation (C0056)
5. For quick commissioning you select the "Quick start" menu
The submenu "VectorCtrl qu" contains the codes
which you require for commissioning a standard
application. The digital inputs are configured in Lenze
setting:
X3/E1, X3/E2: activation of fixed setpoints (JOG)
X3/E3: activation of DC injection brake (DCB)
X3/E4: CW rotation/CCW rotation
A Change the menu level with
B Change to the "Quick start" menu and there to the "VectorCtrl
qu" submenu with
C Change to the code level with to parameterise your drive
6. Adapt the voltage/current range for the analog setpoint selection
(C0034)
Lenze setting: 0, (0 ... 5 V/0 ... 10 V/0 ... 20 mA)
Set the DIP switch on the standard I/O to the same
range (see Mounting Instructions for the standard I/O)
7. If required, adapt the fixed setpoints JOG.
A JOG 1 (C0037)
Lenze setting: 20 Hz
Activation:
X3/E1 = HIGH, X3/E2 = LOW
B JOG 2 (C0038)
Lenze setting: 30 Hz
Activation:
X3/E1 = LOW, X3/E2 = HIGH
C JOG 3 (C0039)
Lenze setting: 40 Hz
Activation:
X3/E1 = HIGH, X3/E2 = HIGH
8. Set the minimum output frequency (C0010)
Lenze setting: 0.00 Hz
9. Set the maximum output frequency (C0011)
Lenze setting: 50.00 Hz
10. Set the acceleration time T
ir
(C0012)
Lenze setting: 5.00 s
11. Set the deceleration time T
if
(C0013)
Lenze setting: 5.00 s
12. Activate the operating mode "vector control" (C0014 = 4)
Lenze setting: Linear V/f characteristic control (C0014 = 2)
13. Enter the motor data See motor nameplate
A Rated motor speed (C0087)
Lenze setting: 1390 rpm
B Rated motor current (C0088)
Lenze setting: depending on the controller
Enter the value for the motor circuit configuration
(star/delta) selected!
C Rated motor frequency (C0089)
Lenze setting: 50 Hz
D Rated motor voltage (C0090)
Lenze setting: depending on the controller
Enter the value for the motor circuit configuration
(star/delta) selected!
E Motor cosj (C0091)
Lenze setting: depending on the controller
