Commissioning
Parameter setting with E82ZBC keypad
7
168
EDK82EV903 DE/EN/FR 5.1
7.2 Parameter setting with E82ZBC keypad
Read the documentation for the keypad before starting work!
After every mains switching, or after connection of the keypad during operation, the 10
codes that have been defined in code C0517 are immediately available.
By default, the user menu contains all codes required for commissioning a standard
application with linear V/f characteristic control:
Code Designation Lenze setting
C0050 Output frequency Display: output frequency without slip compensation
C0034 Range of setpoint selection 0
Standard I/O X3/8: 0 ... 5 V / 0 ... 10 V / 0 ... 20 mA
Application I/O
X3/1U: 0 ... 5 V / 0 ... 10 V
X3/2U: 0 ... 5 V / 0 ... 10 V
C0007 Fixed configuration digital
inputs
0
E4 E3 E2 E1
CW/CCW DCB JOG2/3 JOG1/3
Clockwise
rotation/counte
r−clockwise
rotation
DC injection
brake
Selection fixed setpoints
C0010 Minimum output frequency 0.00 Hz
C0011 Maximum output frequency 50.00 Hz
C0012 Acceleration time main
setpoint
5.00 s
C0013 Deceleration time main
setpoint
5.00 s
C0015 V/f rated frequency 50.00 Hz
C0016 V
min
boost device−dependent
C0002 Parameter set management Re−establish delivery status; transfer parameter sets by
means of the keypad; save, load, or copy own basic settings
Note!
Via C0002 "Parameter set transfer/establishing the delivery status", you can
transfer configurations from drive controller to drive controller by means of
the keypad, or re−establish the delivery status by loading the Lenze setting
(e. g. if you’ve lost track during parameterising).
