EDK82EV903 DE/EN/FR 5.1
Key for overview
Interfaces and displays
Position Description Function
2 light−emitting diodes (red,
green)
Status display 183
AIF interface
(automation interface)
Slot for communication module
e. g. E82ZBC keypad
165
FIF Iinterface
(f i i f )
With cover for operation without function module
162
(function interface)
or slot for function module
FIF II interface
(f i i f )
With cover for operation without function module
(function interface)
or slot for function module
E82EV153K4B ... E82EV303K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
8200 vector frequency inverter
Fixing bracket for standard mounting 120
Blanking covers (2 pieces) for interfaces FIF I and FIF II 162
EMC shield sheet with fixing screws for shielded control cables 142
Cover with fixing screws
EMC shield sheet for the motor cable and for the incoming motor temperature monitoring cable 146
Label (required for mounting in accordance with UL) 119
T1, T2 PTC connection or thermal contact (NC contact) of the motor 146
U, V, W, PE Motor connection 146
L1, L2, L3, PE Mains connection 143
+U
G
, −U
G
DC supply
X1.2 Terminal strip for connection of relay output K1
155
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
SR
for "safe standstill" (only for variant Bx4x) 157
E82EV453K4B ... E82EV553K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
8200 vector frequency inverter
Fixing bracket for standard mounting 126
Blanking covers (2 pieces) for interfaces FIF I and FIF II 162
EMC shield sheet with fixing screws for shielded control cables 142
Cover with fixing screws
Shield clamp and strain relief for the motor cable
150
Strain relief for the protective earth cable of the motor and the incoming cable of the motor tempera-
ture monitoring with PTC thermistor (PTC) or thermal contact (NC contact)
Label (required for mounting in accordance with UL) 119
T1, T2 PTC connection or thermal contact (NC contact) of the motor 150
U, V, W, PE Motor connection 150
L1, L2, L3, PE Mains connection 147
+U
G
, −U
G
DC supply
X1.2 Terminal strip for connection of relay output K1
155
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
SR
for "safe standstill" (only for variant Bx4x) 157
