Lenze 8200 vector series Mounting Instructions

Troubleshooting and fault elimination
Fault elimination
Fault messages
8

186
EDK82EV903 DE/EN/FR 5.1
8.3.2 Fault messages
Keypad PC
1)
Fault Cause Remedy
noer
0 No fault − −
ccr
"
71 System fault
Strong interference injections on the
control cables
Shield control cables
Earth loops in the wiring
ce0
"
61 Communication error
on AIF
(configurable in C0126)
Faulty transmission of control
commands via AIF
Insert the communication module firmly
into the diagnosis terminal
ce1
"
62 Communication error
on CAN−IN1 with sync
control
CAN−IN1 object receives faulty data, or
communication is interrupted
l Check plug connection bus module ó FIF
l Check transmitter
l Increase monitoring time in C0357/1, if
necessary
ce2
"
63 Communication error
on CAN−IN2
CAN−IN2 object receives faulty data, or
communication is interrupted
l Check plug connection bus module ó FIF
l Check transmitter
l Increase monitoring time in C0357/2, if
necessary
ce3
"
64 Communication error
on CAN−IN1 with event
or time control
CAN−IN1 object receives faulty data, or
communication is interrupted
l Check plug connection bus module ó FIF
l Check transmitter
l Increase monitoring time in C0357/3, if
necessary
ce4
"
65 BUS−OFF
(many communication
errors occurred)
Controller has received too many faulty
telegrams via the system bus and has
been disconnected from the bus
l Check bus termination
l Check shield connection of the cables
l Check PE connection
l Check bus load, reduce the baud rate, if
necessary
ce5
"
66 CAN time−out
(configurable in C0126)
For remote parameterisation via the
system bus (C0370):
Slave does not respond.
Communication monitoring time has
been exceeded
l Check wiring of the system bus
l Check system bus configuration
For operation with application I/O:
Parameter set change−over has been
parameterised incorrectly
The "parameter set change−over" signal
(C0410/13, C0410/14) must be connected to
the same source in all parameter sets
For operation with module on FIF:
Internal error
Contact Lenze
ce6
"
67 System bus (CAN)
function module on FIF
has the "Warning" or
"BUS−OFF" status
(configurable in C0126)
CAN controller reports "Warning" or
"BUS−OFF" status
l Check bus termination
l Check shield connection of the cables
l Check PE connection
l Check bus load, reduce the baud rate, if
necessary
ce7
"
68 Communication error
during remote
parameterisation via
system bus (C0370)
(configurable in C0126)
Node does not respond or is not
available
l Check bus termination
l Check shield connection of the cables
l Check PE connection
l Check bus load, reduce the baud rate, if
necessary
For operation with application I/O:
Parameter set change−over has been
parameterised incorrectly
The "parameter set change−over" signal
(C0410/13, C0410/14) must be connected to
the same source in all paramerter sets
EEr
"
91 External fault (TRIP−SET) A digital signal assigned to the TRIP−Set
function is activated
Check external encoder
ErP0
...
ErP19
"
− Communication abort
between keypad and
standard device
Various Contact Lenze
