Mechanical installation
Standard devices in the power range 15 ... 30 kW
Mounting in "cold plate" technique
4
123
EDK82EV903 DE/EN/FR 5.1
4.2.3 Mounting in "cold plate" technique
For this mounting variant you require the controller type E82CV...
The following points are important for safe and reliable operation of the controller:
ƒ Good thermal connection to the cooler
The contact surface between the collective cooler and the controller must be at
least as large as the cooling plate of the controller.
Plane contact surface, max. deviation 0.05 mm.
When attaching the collective cooler to the controller, make sure to use all
specified screw connections.
ƒ Observe the thermal resistance R
th
given in the table. The values are valid for
controller operation under rated conditions.
Power to be dissipated by the heatsink Cooling path of heatsink − ambience
8200 vector P
v
[W] R
th
[K/W]
ÑÑÑÑÑÑ
ÑÑÑÑÑÑ
E82CV153K4B
ÑÑÑÑÑÑÑÑÑÑÑÑ
ÑÑÑÑÑÑÑÑÑÑÑÑ
287
ÑÑÑÑÑÑÑÑÑÑÑÑÑ
ÑÑÑÑÑÑÑÑÑÑÑÑÑ
£ 0.085
ÑÑÑÑÑÑ
E82CV223K4B
ÑÑÑÑÑÑÑÑÑÑÑÑ
427
ÑÑÑÑÑÑÑÑÑÑÑÑÑ
£ 0.057
Ambient conditions
ƒ The rated data and the derating factors at increased temperature also apply to the
ambient temperature of the drive controllers.
ƒ Temperature at the cooling plate of the drive controller: max. 75 °C.
