Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 55 –
LLDP 321
Configure Global Configures global LLDP timing parameters 321
Configure Interface 323
Configure General Sets the message transmission mode; enables SNMP notification; and
sets the LLDP attributes to advertise
323
Add CA-Type Specifies the physical location of the device attached to an interface 327
Show Local Device Information 329
General Displays general information about the local device 329
Port/Trunk Displays information about each interface 329
Show Remote Device Information 333
Port/Trunk Displays information about a remote device connected to a port on this
switch
333
Port/Trunk Details Displays detailed information about a remote device connected to this
switch
333
Show Device Statistics 341
General Displays statistics for all connected remote devices 341
Port/Trunk Displays statistics for remote devices on a selected port or trunk 341
PoE
*
Power over Ethernet 343
PSE Power sourcing equipment 343
Configure Global Set the maximum PoE power budget for the switch (power available to
all Gigabit Ethernet ports)
Configure Interface Configures port power parameters
SNMP Simple Network Management Protocol 347
Configure Global Enables SNMP agent status, and sets related trap functions 349
Configure Community 362
Add Configures community strings and access mode 362
Show Shows community strings and access mode 362
Configure Engine 350
Set Engine ID Sets the SNMP v3 engine ID on this switch 350
Add Remote Engine Sets the SNMP v3 engine ID for a remote device 351
Show Remote Engine Shows configured engine ID for remote devices 351
Configure View 353
Add View Adds an SNMP v3 view of the OID MIB 353
Show View Shows configured SNMP v3 views 353
Add OID Subtree Specifies a part of the subtree for the selected view 353
Show OID Subtree Shows the subtrees assigned to each view 353
Table 4: Switch Main Menu (Continued)
Menu Description Page
