Publication date: June, 2015
Revision A1
Chapter 1 Operation of Web-based
Management
Initial
Configuration
This chapter instructs you how to configure and manage the GEP-2651 through the
web user interface. With this facility, you can easily access and monitor through any
one port of the switch all the status of the switch, including MIBs status, each port
activity, Spanning tree status, port aggregation status, multicast traffic, VLAN and
priority status, even illegal access record and so on.
The default values of the GEP-2651 are listed in the table below:
After the GEP2651 has been finished configuration the it interface, you can browse it.
For instance, type http://192.168.1.1 in the address row in a browser, it will show the
following screen and ask you inputting username and password in order to login and
access authentication.
The default username is “admin” and password is “admin”. For the first time to use,
please enter the default username and password, and then click the <Login> button.
The login process now is completed. In this login menu, you have to input the
complete username and password respectively, the GEP-2651 will not give you a
shortcut to username automatically. This looks inconvenient, but safer.
In the GEP-2651, allowed two or more users using administrator’s identity to manage
this switch, which administrator to do the last setting, it will be an available
configuration to effect the system.
NOTE:
When you login the Switch WEB/CLI to manager. You must first type the
Username of the admin. Password was blank, so when you type after the
end Username, please press enter. Management page to enter WEB/CLI.
When you login GEP-2651 series switch Web UI management, you can use
both ipv4 ipv6 login to manage
To optimize the display effect, we recommend you use Microsoft IE 6.0
above, Netscape V7.1 above or FireFox V1.00 above and have the resolution
1024x768. The switch supported neutral web browser interface
