b. PID: If the OUI is hexadecimal 000000, the protocol ID is the Ethernet type (EtherType)
field value for the protocol running on top of SNAP; if the OUI is an OUI for a particular
organization, the protocol ID is a value assigned by that organization to the protocol
running on top of SNAP.
In other words, if value of OUI field is 00-00-00 then value of PID will be etype
(0x0600-0xffff) and if value of OUI is other than 00-00-00 then valid value of PID will be any
value from 0x0000 to 0xffff.
Group Name :
A valid Group Name is a unique 16-character long string for every entry which consists of a
combination of alphabets (a-z or A-Z) and integers(0-9).
NOTE:
special character and underscore(_) are not allowed.
Buttons
Auto-refresh: Check this box to refresh the page automatically. Automatic refresh occurs
every 3 seconds.
Refresh: Click to refresh the page.
