Network Topology
All Master/Remote panels must be connected in a daisy-chained fashion. For example,
please consider the illustrations below:
Figure 9: The right way - Daisy-Chain Wiring
Category 5 or better wiring between cabinets
48 Relay Master Cabinet
24 Relay Remote Cabinet
4 Relay Remote Cabinet 4 Relay Remote Cabinet 4 Relay Remote Cabinet
Figure 10: The wrong way - Star or other scheme
5HOD\0DVWHU&DELQHW
5HOD\5HPRWH&DELQHW
5HOD\5HPRWH&DELQHW
5HOD\5HPRWH&DELQHW
5HOD\5HPRWH&DELQHW
'RQRWZLUHDVVKRZQ
