Leviton EZ-MAX - Cabinet Start Address;Automatic Luma-Net Channel Assignment; Operation Mode

Page 50
Cabinet start address/Automatic Luma-Net channel
assignment
The Luma-Net channel assignment for each relay can be automatically assigned from
the start address defined for the cabinet. To assert this automatic channel
assignment, simply change the start address under this menu. All relays will be
automatically and incrementally renumbered starting from the new start address.
Operation Mode
Participation on the Luma-Net network can be enabled or disabled from this
menu item.
Master Feedback
Feedback is the ability of a relay to respond to a status request. For example, a
network device might ask for the on/off status of relay #13. If Master Feedback is on
AND relay #13 is instructed to respond to feedback messages, the relay cabinet will
respond with the current on/off state of the relay. Likewise, if Master Feedback is OFF
and regardless of the feedback setting in the relay menu, the cabinet will not respond
to any request for status.
LUMA-NET SETUP
START ADDR: 1
LUMA-NET SETUP
OP MODE: DISABLED
LUMA-NET SETUP
MASTER FB: DIS
Thi
s se
tti
ng can
b
e use
d
t
o qu
i
c
kl
y
i
so
l
a
t
e
problems related to multiple relays responding to
the same request for level. If multiple responses
are made, the Luma-Net network will constantly
crash.
