Switch/Discrete Inputs Assign Actions to Inputs
Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 73
Step 1: Press or to select desired relay/group entry to edit.
Step 2: Press Select/Save to begin editing.
Step 3: Press or to change between relay or group if desired.
Step 4: Press to move to the number field to make appropriate changes
using and .
Step 5: Press Select/Save to save the changes.
DEL RELAY/GROUP:
This menu allows previously programed Relay/Group items to be deleted.
From the end of the previous step:
Step 1: Press or to select desired relay/group entry to delete.
Step 2: Press Select/Save to initiate the deletion.
Step 3: The LCD will prompt for confirmation.
Step 4: Press to change the default "N", for No, to "Y’, for Yes.
Step 5: Press Select/Save to delete the item.
EXIT (DONE):
This item will move back up to ASSIGN ACTIONS menu.
Switch Inputs
There are six behaviors that can be assigned to a switch input:
• Momentary
• Maintained
• Preset On
• Preset Off
SWITCH:006 LOCAL
EDIT RELAY/GROUP
SWITCH:006 LOCAL
DEL RELAY/GROUP
DELETE Y/N? Y
Del 1:RLY 01-01
