Occupancy Sensor Configuration
Occupancy sensors are devices which sense when a person enters a particular room
or area. Leviton’s Occupancy Sensor’s are designed for a variety of applications, using
a variety of technologies which can be applied to your specific need. The Occupancy
sensors which this relay panel is designed to work with are those which are powered
by +24Vdc and provide a ~+24Vdc output when the covered area is occupied.
These instructions assume that your Occupancy Sensor is connected to the OCC input.
If your Occupancy Sensor is connected to one of the other inputs, configuration will
be similar.
Step 1: Using the menu navigation buttons, navigate the menus to Configuration,
Config Inputs, then to Occ Sensor, and press Select/Save
Step 2: Enter the Input number to which your occupancy sensor is connected. If
connected to the input labeled "Occ Sensor", the input number should be
"OCC"
Step 3: Enable or Disable this occupancy sensor
Step 4: Enter the Behavior of the occupancy sensor
The choices for behavior are as follows:
• Manual On - The occupancy sensor will turn off the assigned relays when
the occupancy sensor indicates an occupied state. When the room become
occupied, the relays will not be automatically turned on, instead, the user
will have to manually turn on the lights from a wall switch or other input.
• Auto On - In this mode, the Occupancy Sensor will turn the assigned
relays both on and off based on either an occupied or unoccupied stated
indicated by the occupancy sensor
CONFIG INPUTS
OCC SENSOR
ENTER OCC SENSOR
INPUT NUMBER:OCC
OCCSEN:001 LOCAL
ENABLED: YES
SELECT BEHAVIOR
MANUAL ON
