Page 56
Here is how you decipher the screen:
• Day and Time - The clock can display in either 12 or 24 hour mode.
• Daylight Savings settings for 12 Hour Clock
• Lower case "a" or "p" indicates that daylight savings is inactive
• Uppercase "A" or "P" indicates that daylight savings is active
• Daylight Savings settings for 24 Hour Clock
• Lower case "s" indicates that daylight savings is inactive
• Lower case "d" indicates that daylight savings is active
• Panel Lock Status
• "L" indicates that the panel is in a locked state
• "u" indicates that the panel is in a temporary un-locked state and will
automatically lock after 3 minutes of inactivity
• "U" indicates that the panel is in an un-locked state and will not automatically
enabled the lock
• Event Scheduler
• "E" will either show
• "OFF" Indicating that the event scheduler is turned off
• "---" indicates that no events have executed since the last system reset/
power cycle
• a number indicates the number of the last event executed
• Bottom Line - If an EZ-Max panel, shows the current status of the four relays in
your panel. Either On, or Off. An asterick (*) adjacent to any relay indicate that
particular relay is in an override state. The override could be either a timed override
or other front panel override. If the panel is not an EZ-Max panel, this bottom line
shows any relevant status messages.
Programming/Function Buttons
The several programming buttons are located around the display:
• MENU. Allows the user to navigate through the system
• SELECT/SAVE. Causes a new readout on the LCD display.
• CANCEL: Returns to the previous menu
• CLEAR. Clears the text or value that was just entered.
• RELAY ON/OFF: Button that allows a user to turn a relay ON or OFF, execute a
timed override, or execute a permanent relay override.
• LOCK/UNLOCK: Locks and Unlocks the user interface.
Many parameters can be modified using the LCD screen and a
password (setup code), however these modifications should be made
by a qualified factory technician.
Navigation Buttons
The lower center four buttons, used for navigation of menu items, are LEFT , UP
, DOWN , and RIGHT . Generally, the LEFT and RIGHT
buttons are used to navigate between ’fields’ on the screen, whereas the UP
and DOWN buttons generally change values in the fields.
