• 25-72 reserved for remote relays
• 73-240 reserved for network/digital switch inputs
Define Switch Types
The system programming is defaulted for all input types to be set up as Switches and
their behavior as Active High. If you do not have any other type of input or behavior
type, then you can skip this section.
To define the type of switch input
Step 1: Once "Define Types" has been selected from the menus, press or
enter a number from the keypad until you get to the desired input
number or type in the three digit number from the keypad.
Step 2: Press Select/Save
Step 3: Press until you reach the desired switch type. The following are the
choices:
• SWT = Switch
• PHO = Photocell
• OCC = Occupancy Sensor
• CC = Contact Closure
• --- = nothing connected
Step 4: Press . once to position the cursor in the next field
Step 5: Press the or to toggle the input behavior field to the desired
value. See the following list for the available behavior types:
• SWT = Switch
• Act HIGH - Active High (All Leviton Low Voltage Switches and Z-MAX
Digital Switches)
• Act LOW - Active Low
• PHO = Photocell
• Fc:1-999
• OCC = Occupancy Sensor
• Act HIGH - Active High
• Act LOW - Active Low
• CC = Contact Closure
• Act HIGH - Active High
• Act LOW - Active Low
Step 6: Press Select/Save and the following menu will appear whenever an input
type is changed. Relays and parameters previously assigned to that
input will be deleted:
DISCRETE INPUTS
DEFINE TYPES
CHANGE FORMAT? N
Data Kept As Is!
