Leviton EZ-MAX - Termination Requirements

Page 146
Termination Requirements
Both ends of the control run must be terminated. Nodes not at each end of the run
must not
be terminated (see figure 9.)
For most Luma-Net devices, termination can be achieved by connecting a short pieces
of wires between the "TERM" and "REM-" terminals (see figure 8.) On other devices,
like relay and dimmer cabinets, termination can be achieved by installing the
termination jumper located adjacent to the Luma-Net connector inside the relay
cabinet or other device. (see figure 10.)
Figure 8: Luma-Net Node Termination Jumper
Mi
ss
i
ng
t
erm
i
na
ti
on, ex
t
ra
t
erm
i
na
ti
on, or
l
ac
k
o
f
termination can cause sporadic or even non-
existent data communication. Carefully plan out
where termination must occur and executed.
REM+
REM -
COM
TERM
LOCK
+V
1
2
3 4 5
6
Termination Jumper
5
6
1
2
3
4
Phoenix/Luma-Ne
t
Connector
