Leviton EZ-MAX - General Requirements for Connecting any Device to Low Voltage Inputs

Low Voltage Control Wiring Control Overview
Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 157
Input Power Requirements
The relay cabinet has a finite amount of power which it can supply to connected
devices. This topic is discussed in detail starting on page 117 entitled "Power
Considerations for Control Systems." Please make sure that you do not exceed the
amount of available peripheral power, or damage to your relay cabinet or connected
devices may occur.
General Requirements for Connecting any Device to Low Voltage
Inputs
Step 1: Connect leads per wiring diagram as illustrated in the figures on the
following pages
Step 2: Twist strands of each lead tightly (make sure that there are no stray
strands) and push firmly into appropriate plug connector location.
Step 3: Tighten the screws on the plug connector—make sure that no bare
conductor is showing.
Step 4: Plug the connector back onto the control module with the screws facing
the front and the wires coming out of the connector toward the top of
the cabinet.
F
or or
d
er
i
ng
i
n
f
orma
ti
on on
th
e po
l
ar
it
y
IC’
s an
d
additional recommendations for active low
inputs, please contact technical services at
(800)959-6004.
