Leviton EZ-MAX - Ethernet Module; Operation Mode

Ethernet Module
Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 63
Ethernet Module
Z-Max relay panels can be configured to participate on an TCP/IP Ethernet network.
From the ethernet network you can operate your panel from the command line
interface (CLIF) or you can transfer data to/from various applications.
Operation Mode
The ethernet card has two operation modes:
•
Ethernet - The ethernet module is installed
•
None - indicates that no module is installed or both modem and ethernet access
should be disabled
DHCP
On networks which support DHCP for IP address allocation, your ethernet card can be
configured to retrieve it’s address from a DHCP server. If you have a DHCP server on
your network, this option should be enabled.
IP Address
If DHCP is disabled, you will be asked for an IP address. Please enter a unique IP
address when requested.
Subnet Mask
If DHCP is disabled, you will be asked for an subnet mask. Please enter the
appropriate mask when requested.
MAIN MENU SELECT
CONFIGURATION
MENU
CONFIGURATION
SYSTEM SETUP
SYSTEM SETUP
PHONE/ETHERNET
Alth
oug
h
thi
s par
t
o
f
th
e menu s
t
ruc
t
ure
i
s
entitled phone/ethernet, this section only covers
ethernet setup and configuration. The mode
module configuration is covered in a previous
chapter.
PHONE/ETHERNET
MODE: ETHERNET
ETHERNET
DHCP: ENABLED
ETHERNET IP ADDR
192.168.001.002
ETHERNET IP MASK
255.255.255.0
