Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 47
Step 5: Enter "57" from the keypad
Step 6: Press to save your settings and continue to editing other relays or
relay parameters.
Turning feedback On or Off:
The feedback setting is used to toggle Luma-Net feedback on or off. When Luma-Net
feedback is on for a relay, it means that when a level request is issued from that
network, the relay with feedback "on" for that channel will respond.
To alter if a relay will respond to a blink warn message.
Sometimes, it is necessary to override the relay so it will not respond to a blink warn
command. This is especially true of HID fixtures. This feature can be used to turn off
or on blink warn for a particular relay. When blink warn is turned off for a relay, the
relay will not blink before turning off.
To change the Luma-Net address for a specific relay
This setting can be used to change the Luma-Net channel assignment only for this
relay. More than one relay may be assigned to the same Luma-Net channel.
To change the DMX Address for a specific relay
Each relay can be assigned a dmx channel. This channel can be assigned/modified
from this menu option. By default every relay is assigned a sequential channel starting
at the relay cabinets starting channel number as defined from the global defaults
menu.
RELAY 1 LOC
GROUP 2: 57
SELECT
RELAY 1 LOC
FEEDBACK: YES
Wh
en more
th
an one re
l
ay
i
s ass
i
gne
d
t
o
th
e
same Luma-Net channel, only one of them
should have feedback turned on.
RELAY 1 LOC
BLINK WARN: YES
RELAY 1 LOC
LUM ADDR: NONE
RELAY 1 LOC
DMX ADDR: NONE
If
on
l
y
th
e s
t
ar
ti
ng a
dd
ress nee
d
s
t
o
b
e se
t
f
or
the relay cabinet, this can be set in the Luma-
Net menu under system setup.
RELAY 1 LOC
DMX ADDR: NONE
If only the starting channel needs to be set for
the relay cabinet, this can be set from the DMX
menu under system setup.
