Page 84
Step 24: Press Select/Save
The Following are the actions items that can be added:
• RLY (Relay)
• GRP (Group)
• BTN (Button)
• PHO (Photo Cell)
• OCC (Occupancy Sensor)
• ACT (Action)
• EVT (Event)
Step 25: Press until you get to the desired item
Step 26: Press Select/Save
Action Item Types:
Relay
This action item puts a relay or a range of relays into one of 5 states:
• REL: Relinquish releases control of the relay at the priority level specified. If
the action at this priority was currently in control of the relay, control will be
transferred to the next lower priority level action that is in any of the four other
states.
• OFF: Turns the relay off.
• ON: Turns the relay on.
• BWO: Activates the Blink Warn sequence for the selected relays provided Blink
Warn has been activated for each relay from the Setup Menu. See the Global
Default settings for Blink Warn timing settings.
• BWC: Cancels the Blink Warn operation for the selected relays.
Step 27: Press once to position the cursor in the first relay field
Step 28: Press and until you get to the desired starting relay
Step 29: Press once to position the cursor in the second relay field
Step 30: Press and until you get to the desired ending relay
Step 31: Press once to position the cursor in the relay state field
Step 32: Press until you get to the desired relay state (see above for the
types of states)
ACTION CHOOSE TO
ADD A NEW ITEM
ADDING NEW ITEM
RLY 01-01 REL De
