Physical Specifications
Leviton stipulates that all control and power wiring must be in
conduit. Additionally and as is common with all digital control signals,
the cable should not pass near any source of electrical noise such as
fluorescent circuits or motor wiring. Avoid close proximity to any AC
wiring.
Specification Description
Maximum End to End Run Length 2,000 feet
Maximum number of controlled channels
per subnet
2,048
Maximum number of nodes per subnet on
the network
255
Network Topology Daisy-Chain
Interconnection Method Terminal
Wiring Specifics (1) Twisted Data Pair plus a common
required for digital communication signal
Node power requires additional power
wiring
Supported Voltage +12-24Vdc
Minimum voltages for node functionality varies depending on node type, usually
+10Vdc
Recommended Wire
(includes data and power pair)
Belden 1502R
Belden 1502P (Plenum)
Alternate Approved Wire Belden 9729,9829,8102,9841,
89729,88102
Alpha 6222C, 6412
Network Protocol Leviton Luma-Net
on RS-485
Conflicting or Multiple Control Message
Mitigation Strategy
Last Action Takes Precedence
Termination Requirements Terminate at both ends of control run
Data- to common with 100-120ohm
resistor
