Page 12
LED Label LED State Indication
EMERGENCY Solid Red Indicates system is in emergency state
Off System is in Normal State
HEARTBEAT-C Slow Blinking Amber
(~1 bps)
Control Module Microprocessor is operating
properly
Fast Blinking Amber
(~2 bps)
Control module microprocessor is in boot
mode
Off Control Module Microprocessor off line -
usually indicates system failure
Luma-Net Solid Green Configured (Negotiating a connection)
Off Disabled
Fast Flash Negotiating connections/initialization
Slow Flash Connected, TX/RX data
DMX Blinking Mostly On Receiving Valid DMX Data
Solid DMX enabled but no data receive
Off Either Disabled or Not receiving Valid Data
CAN 1 (Master/Remote) Blinking Green Enabled, Receiving Data
Solid Green Enabled, but not currently receiving data
Off
CAN 2 N/A Not currently in use
ETH/MODEM Solid Green Indicates modem or ethernet module is
installed, enabled, and link is established
5V POWER Solid Amber +5V power supply working normally
HEARTBEAT-R Slow Blinking Amber Relay Communications Microprocessor
operating properly
Fast Blinking Amber Relay Communications Microprocessor
detects a hardware alert
Off Relay Communications Microprocessor Off
Line
