Page 42
The following relay types are possible:
•
STD NO - The standard relay type. A normally open relay which is electrically held
open. Leviton part number RELAY-STD
•
Latching - Leviton’s latching relay module which is mechanically held in the last
position indicated by the relay cabinet. P/N #RELAY-LAT
•
STD NC - Normally closed relay module which requires electricity to keep the relay
off.
•
ST SEN L - Sentry switch Long is for use only with Leviton relay module P/N RELAY-
STD. This unique relay type can be used in conjunction with sentry switches.
When an Off command is issued, the relay will shut off for a brief time period and
then turn back on. This signals the downstream Sentry Switch to turn off the lights,
however, the circuit remains energized.
•
ST SEN S - Sentry switch Short is for use only with Leviton relay module P/N
RELAY-STD and is designed to be used with WattStopper AS-100 style switches
which require a short pulse to signal the lights turning off yet the relay must remain
on.
•
NC SEN L - Is just like ST SEN L except designed to be used with a normally closed
relay module.
•
NC SEN S - Is just like ST SEN S except designed to be used with a normally closed
relay module.
•
PULSE - type is currently unsupported
•
CUSTOM - type is currently unsupported.
Set Blink Warn for All relays
This setting allows a quick method by which to turn on or off Blink Warn for all relays.
• Y = indicates blink warn should be enabled for all relays
• N = indicates blink warn should be disabled for all relays
After this setting has been applied, and regardless of this setting, you can still turn on
or off blink warn for each relay in the relay menu.
Set Level Feedback for all relays
This entry will quickly set feedback for all relays controlled by this cabinet also to the
indicated value.
• Y = indicates feedback should be enabled for all relays
• N = indicates feedback should be disabled for all relays
After this setting has been applied, and regardless of this setting, you can still turn on
or off the feedback setting for each relay in the relay menu.
Set Emergency setting for all relays
This setting allows a quick method by which to set the Emergency setting for all
relays.
• ON = sets each relay to turn on when emergency mode is active
• OFF = sets each relay to turn off when emergency mode is active
Ch
ang
i
ng
thi
s se
tti
ng w
ill
c
h
ange
th
e re
l
ay
t
ype
for ALL relays in the cabinet, even those to
which you have already applied a specific relay
type.
GLOBAL DEFAULTS
RLY SET ALL BW: Y
GLOBAL DEFAULTS
RLY SET ALL FB:Y
GLOBAL DEFAULTS
RLY SET EMERG: NC
