Switch/Discrete Inputs Assign Actions to Inputs
Z-Max Advanced Programming & Systems Design Guide rac00-sdg
Revision A:11/2005 Page 75
discrete input. The only difference is the way they are wired to the system and how
they are networked over Luma-Net. Set up is very similar in philosophy.
For information about inputs which are available for use as a digital switch input, See
“Switch Numbering” on page 69.
To set up a digital switch:
Step 1: Press the Menu Button
Step 2: Press until you get to the Configuration Screen
Step 3: Press Select/Save
Step 4: Press until you get to the Discrete Inputs Screen
Step 5: Press Select /Save
Step 6: Press until you get to the Define Types Screen
Step 7: Press Select /Save
Step 8: Press until the flashing field reads 49 or greater (this depends on
which switch you are trying to set up)
You can also type in the 3 digit number of the switch. Therefore if
you are trying to set up 49, type 049 from the keypad.
Step 9: Press Select/Save
Step 10: The Cursor will jump to the type field and if still at factory default
values, will be flashing SWT as Shown:
Step 11: Press until SWT is in the field
Step 12: Press . once to position the cursor in the next field
Step 13: Press until Act HIGH is in the field
Step 14: Press Select/Save to store the settings and move you to the next
screen
Step 15: Press. once to position the cursor in the field marked ADD. This is
the Luma-Net network address of the digital switch you are
programming.
Step 16: Press until you get to the desired network address
Step 17: Press . once to position the cursor in the field marked BT. This
refers to the physical button number on the station itself.
Step 18: Press until you get to the desired button
Step 19: Press Select/Save
SET INPUT TYPES
049:SWT Act HIGH
SET NETWORK: ecl
ADD: X BT: X
To Next Page
