Note:Theviewinganglesstatedaboveweretaken
usinginternationallyagreedstandardsandshould
beusedforcomparisonpurposesonly.DoNOT
installtheproductbeforetestingitsviewabilityin
thedesiredlocation.
aSeriesDisplayspecication
a6xa7xa9xa12x
Size
5.7in7in9.0in12.1in
TypeTFT
backlit
LED
TFT
backlit
LED
TFT
backlit
LED
TFT
backlit
LED
Color
depth
24–bit24–bit24–bit24–bit
Resolu-
tion
640x480
VGA
800x480
WVGA
800x480
WVGA
1280
x800
WXGA
Aspect4:316:916:916:9
Maxi-
mumal-
lowable
wrongly
illumi-
nated
pixels
5
666
Dataconnections
Wiredconnections
NMEA01832xNMEA0183ports:
•NMEAport1:Inputandoutput,
4800/38400baud
•NMEAport2:Inputonly,4800/
38400baud
Note:NMEA0183connection
doesnotapplytoa6xanda7x
variantMFDs.
Network(SeaTalk
hs
)•a6x/a7x,e7ande7D=1x
SeaTalk
hs
port.100Mbits/s.
RayNettypeconnection.
•a9x,a12x,cSeriesandeSeries
(excludinge7ande7D)=2x
SeaTalk
hs
port.100Mbits/s.
RayNettypeconnection.
SeaTalk
ng
1xSeaTalk
ng
connection
Wirelessconnections
Wi-Fi
802.11b/g
Note:Wi-Ficonnectiononly
appliestomultifunctiondisplays
thatincludebuilt-inWi-Fi.
BluetoothBluetooth2.1+EDRpowerclass
1.5(supportedprole:AVRCP1.0)
a9xanda12xDataconnections
Wiredconnections
NMEA0183•NMEAport1:Inputandoutput,4800
/38400baudrates
•NMEAport2:Inputonly,4800/
38400baudrates
Note:a6xanda7xvariantMFDsdo
notincludeNMEA0183connections
Network
(SeaTalk
hs
)
•a6xanda7x=1xRayNettype
SeaTalk
hs
port.10/100Mbits/s
•a9xanda12x=2xRayNettype
SeaTalk
hs
port.10/100Mbits/s
SeaTalk
ng
1xSeaTalk
ng
connection
GA1501xTNCtypeexternalGPS/GLONASS
antennaconnection
Videoinput
1xBNCtypevideoinputconnection
Wirelessconnections
Wi-Fi
802.11b/g
BluetoothBluetooth2.1+EDRpowerclass1.5
(supportedprole:AVRCP1.0)
InternalGPSspecication
TheInternalGPSspecicationappliestothe
followingMFDsaSeries(excludinga9xanda12x),c
SeriesandeSeries(excludingthee165).
Channels
50
Coldstart
<2minutes
Refreshrate
5Hz
ReceiverICSensitivity
163dBmTracking
SatelliteBasedAiding
System(SBAS)
WAAS+EGNOS+MSAS
Specialfeatures
ActiveJammingReduction
Operatingfrequency
1575.42MHz
SignalAcquisition
Automatic
AlmanacUpdateAutomatic
GeodeticDatumWGS-84,alternatives
availablethroughRaymarine
displays.
UpdateRate1second
Antenna
Ceramicchip
Accuracy
•WithoutSBAS:<=15
metres95%ofthetime
•WithSBAS:<=5metres
95%ofthetime
InternalGNSS(GPS/GLONASS)receiver
specication
Channels
72
Coldstart
<2minutes
428aSeries/cSeries/eSeries
