ReceiverIC
Sensitivity
–167dBm(Tracking)/–148dBm
(Acquisition)
GNSS
compatibility
•GPS
•GLONASS
•*Beidou
SBAS
compatibility
•WAAS
•EGNOS
•MSAS
SpecialfeaturesActiveJammingandInterference
Reduction
Operating
frequency
•GPSL1C/A
•GLONASSL10F
•BeidouB1
SignalAcquisition
Automatic
AlmanacUpdateAutomatic
GeodeticDatumWGS-84(alternativesavailable
throughRaymarineMFD)
RefreshRate10Hz(10timespersecondConcurrent
GNSS)
Antenna
•Internal—Ceramicchipmounted
neartopofunit
•External—GA150external
antennamaybeused
PositionAccuracy
•WithoutSBAS:<=15metres95%
ofthetime
•WithSBAS:<=5metres95%ofthe
time
Note:*Supportedbutnotcurrentlyavailable.A
softwareupdatewillberequiredtoaddsupportfor
thisGNSSwhenitbecomesavailable.AGA150
mustbeconnectedtoreceiveBeidou.Please
checkwithyourRaymarinedealerforfurther
details.
Internalsonarspecication
Theinternalsonarspecicationsonlyapplytosonar
variantmultifunctiondisplayvariants.
Operatingfrequencies50/83/200KHz
Transmitpower
Upto600WRMS,depending
ontransducer
Depthrange
Upto3000ft,dependingon
transducer
Sonar/DownVisionspecication
Channels2xCHIRP(1xsonarand1xDownVision)
Beam
coverage
•Sonar—conicalbeam.
•DownVision—Wide(port/starboard)
andthin(fore/aft)fanbeam.
Depth
Typicaldepthperformanceof189m(600
ft).AppliestobothSonarandDownVision
channels.
Electronicchartspecication
Embeddedelectronic
charts
•LightHouseChartsworldbase
map.
•Navionicsworldbasemap.
Compatible
LightHousecharts
•Vector—LightHousecharts
•Raster—LightHousecharts
Compatible
Navionicschart
cards
•NavionicsReadytoNavigate
•NavionicsSilver
•NavionicsGold
•NavionicsGold+
•NavionicsPlatinum
•NavionicsPlatinum+
•NavionicsFish'NChip
•NavionicsHotmaps
Note:
RefertotheRaymarinewebsite(www.rayma-
rine.com)forthelatestlistofsupportedcharts.
Conformancespecication
Conformancecerticationappliestoalldisplay
variants
Conformance•NMEA2000certication
•WiFiAlliancecertication
•Bluetoothcertication
•Europe:1999/5/EC
•AustraliaandNew
Zealand:C-Tick,
ComplianceLevel2
•FCC47CFRpart15
•IndustryCanadaRSS210
Technicalspecication
429
