LNS TRYTON 112 - APPENDIX C: PROGRAMMING SAMPLE

APPENDICES A - 5
TRYTON 112 CNC
APPENDIX C
PROGRAMMING SAMPLE
MAIN PROGRAM
N... ”M” CODE LATHE IN AUTOMATIC CYCLE
N... SPINDLE STOP
N... COOLANT OFF
N... TURRET TO FEED IN POSITION
N... COLLET OPEN
N... TURRET TO FEED OUT POSITION
N... END OF BAR CHECK
( PROGRAM JUMP) >
N... CLOSE COLLET
N... CLEAR TURRET
N...
PART PROGRAM
N... X, Z, G, F, T, S, M, ...
N... MACHINE PART
N... PARTS CATCHER IN
N... CUT OFF
N... PARTS CATCHER OUT
N...
N...
N... X, Z, G, F, T, S, M, ...
N...
N... PROGRAMM END (LOOP)
> SOB-PROGRAM
N... TURRET HOME
N... “M”CODE (DWELL/LOAD)
N... CLOSE COLLET
N... START SPINDLE
N... COOLANT ON
N... TOP CUT MATERIAL
N...
N...
N... END OF SUB-PROGRAM
(RETURN TO MAIN PROGRAM)
Important: The above is an example only. Programming may change
according to the interface between the lathe and the bar
feed.
