APPENDIX D
CONVERSION TABLE METRIC MEASUREMENTS / INCHES
25,4 mm = 1 Inch
Millimeters Inches
1 0,039
2 0,079
3 0,118
4 0,157
5 0,197
6 0,236
7 0,276
8 0,315
9 0,354
10 0,394
11 0,433
12 0,472
12,70 0,500
APPENDIX E
CONVERSION TABLE FOR SHAPED MATERIALS
The table below makes allows to obtain the diameter
on the points of shaped bars from the diameter across
flat sides
Formulas :
Square = Diameters across flats x 1.414
Hexagonal = Diameter across flats x 1.155
Across flats : d
Hexagonal : D Square : D
1 1,41
2 2,31 2,83
3 3,47 4,24
4 4,62 5,66
5 5,78 7,07
6 6,93 8,48
7 8,09 9,90
8 9,24 11,31
9 10,40
10 11,55
11
12
