 DC Power Input Type:
SV055, 075, 110, 150, 185, 220, 2800, 3150, 3705iV5-4DC
PE
P (+)
N (-)
U
V
W
FX
P1 (MM0)
P2 (MM1)
P3 (ATO)
CM
VREF
AI 1
5G
IM
GE
A+
RA
GE
RB
E
GE
Multi-function input 1
Multi-function input 2
Multi-function input 3
Common
Potentiometer
10 k ohm , 1/2W
Multi-function input
G
Encoder A
Phase input
Note ) : Main circuit , : Control circuit
Shield
P4 (FHM)
P5 (BAT)
P6 (BRC)
P7 (MCC)
STARVERT - iV5
Multi- function input 4
Multi- function input 5
Multi- function input 6
Multi -function input 7
AI 2
AI 3
Power supply (+10 V)
Analog input 1
Analog input 2
Analog input 3
Common
Analog input
(10 ~ -10 V )
(- 1 0 ~ 1 0 V)
(0~10V)
(10 ~ 0V)
(0~20mA)
(20~0mA)
(Motor NTC / PTC)
Encoder B
Phase input
Power supply (5V)
Common (0V)
Open collector
output
AO 1
AO 2
5G
Analog output 1
Analog output 2
Common
Analog
output
(-10 ~ 10V)
(10 ~ -10V)
(0 ~ 10V)
(10 ~0V)
30 A
30 C
30 B
1A
1B
2B
2A
Fault relay output
(~AC250V,1A)
(~DC 30V,1A)
Auxiliary relay
output
(~AC250V,1A)
(~DC 30V,1A)
Open collector
output
(24V,50mA)
OC1
EG
B+
A-
B-
A phase encoder pulse output
B phase encoder pulse output
Encoder output Common
Encoder output Common
AC1
AC2
Aux. power source
for control circuit
Insulated
Trasformer
Note 1)
RX
BX
RST
FWD run /stop command
REV run / stop command
Emergency stop
Fault reset
24 V
(50/60Hz)(220V)
Encoder
( Line Drive Type)
DC input
(540 ~ 680 VDC)
G
※ SIO terminal indication for SV2800~3750iV5: PE → PENT, GE → G24X
Note 1) It is used when inverter control circuit is energized from auxiliary power source (220 VAC) without main
power supply. Use insulated transformer to separate from main power supply. (Transformer capacity: above
100VA recommended)
Main Power Circuit
Control Circuit
