④ Crimp terminal with insulation cap should be used for the input power supply and the motor.
⑤ After finishing wiring, be certain to remove all the wire or cable scraps inside the inverter.
⑥ Use the shield cable or twist-paired wire for control circuit terminal. Do not put them into the same wiring
duct for the power terminal.
⑦ When wiring is changed after operating the inverter, be sure to check LCD window on the keypad or
charge lamp is turned off. Capacitors inside inverter are charged with high voltage and it may result in lethal
injury.
⑧ Below 22kW inverter, B1 and B2 on the power terminal should not be connected to anything else other
than DB resistors.
3.3.4 Main power circuit wire sizes and grounding wire size
① Main Power Circuit Wire Sizes
If wiring for the main power terminal is not performed properly, it may cause severe damage to inverter or
lethal injury to inverter operator. Be sure to use 600V, 75℃ copper wire.
Wire Size (Cabling standards of IEC 60227-3 or UL508C)
mm2 AWG or kcmil
Inverter Capacity
R, S, T U, V, W R, S, T U, V, W
2.2 kW 2.5 2.5 12 12
3.7 kW 4 4 10 10
5.5 kW 6 6 8 8
7.5 kW 10 10 6 6
11 kW 16 16 4 4
15 kW 25 25 3 3
18.5 kW 35 35 2 2
22 kW 35 35 2 2
30 kW 50 50 1/0 1/0
200V
37 kW 70 70 2/0 2/0
2.2/3.7 kW 2.5 2.5 12 12
5.5 kW 4 4 10 10
7.5 kW 4 4 10 10
11 kW 6 6 8 8
15 kW 10 10 6 6
18.5 kW 16 16 6 8
22 kW 16 16 4 4
30 kW 35 35 4 4
37 kW 25 25 3 3
45 kW 50 50 2 2
55 kW 50 50 1 1
75 kW 70 70 2/0 2/0
90 kW 120 120 4/0 4/0
400V
110 kW 150 150 300 300
