Installing and Removing Modules
Installing and Replacing IOP Modules
6-204/5/03 CBX 500 Multiservice WAN Switch Hardware Installation Guide
Redundant IOP Modules
You must install redundant IOP pairs in specific adjacent slots (see Figure 6-9).
Figure 6-9. Redundant-Pair Slots
See Appendix D, “Redundancy” for more information about CBX 500 redundancy.
34 56 78 91210111213141516
SPs
redundant pairs
redundant pairs
