IOP and IOA Module Specifications
4-port ATM UNI OC-3c/STM-1 IOP Module
Beta Draft Confidential
CBX 500 Multiservice WAN Switch Hardware Installation Guide 4/5/03A-25
4-port ATM UNI OC-3c/STM-1 IOP Module
The 4-port OC-3c/STM-1 IOP module provides four 155.52 Mbps interfaces for both
optical and electrical connections. You can configure each port as one of the
following:
• User-to-Network Interface (UNI)
• Interim Inter-switch Signalling Protocol (IISP) port
• Direct trunk
• OPTimum cell trunk
The CBX 500 16-slot, modular architecture provides 56 OC-3c/STM-1 ports per
switch. The OC-3c/STM-1 module has 24K cell buffers per port, enabling you to
customize your network for specific traffic needs. The port buffers and the 128K cell
buffers on the SP are based on the CBX 500 switch quad-plane architecture.
Specifications
Physical Dimensions
Power Requirements
65 Watts (optical and electrical)
Table A-10. 4-port ATM UNI OC03c/STM-1 IOP/IOA Physical
Dimensions
Dimension IOP IOA
Height 17.25in(43.18cm) 23in(58.4cm)
Width 1.06 in (2.69 cm) 1.06 in (2.69 cm)
Depth 12.25 in (30.48 cm) 5 in (12.7 cm)
Weigh 5 lb (2.3 kg) 1.6 lb (.73 kg)
